Product Description: | Built with a quad-core processor, an AES-NI hardware encryption engine, and Btrfs file system support, the DiskStation DS224+ 2-Bay NAS Enclosure from Synology is a compact NAS designed to bring centralized data management to small organizations and teams. The DS224+ is equipped with two drive bays that are capable of natively supporting 3.5" SATA hard drives as well as 2.5" SATA hard drives and SSDs. Using its two drive bays, this NAS will allow you to store and share a large number of files with up to 2048 user accounts and 1500 maximum concurrent connections.
The DS224+ runs on Synology DiskStation Manager (DSM) OS, which is a browser-based operating system which helps to simplify managing your Synology NAS. Its CPU is a 2.0 GHz Intel Celeron J4125 Quad-Core with a burst frequency of up to 2.7 GHz, and its 2GB of DDR4 RAM, which can be upgraded to 6GB, allows frequently used files and applications to be quickly accessed.
Also featured are two USB-A 3.2 Gen 1 ports for connecting external devices, and network connectivity is achieved via the dual integrated Gigabit Ethernet ports that support link aggregation and failover, allowing your stored data to be shared with users throughout the network. Data may also be made remotely available through the free iOS and Android applications. For those who require RAID support, the DS224+ supports RAID 0 and 1, as well Synology Hybrid RAID and Basic RAID, each of which offers performance, data redundancy, or a combination of both. For those who do not require a RAID, JBOD is also available, allowing each drive bay to be individually utilized.
The DS224+ is engineered to be energy efficient. Not only does it offer a 92 x 92mm fan to help keep the system running cool at all times, its noise dampening design, with a rating of 22 dBA, makes for quiet operations. The server supports numerous scheduled power on/off cycles and hard drive hibernation to further minimize power consumption and operation expenses.
The Synology DiskStation DS224+ 2-Bay NAS Enclosure operates on 100-2 |
Product SKU: | 1781611 |
UPC: | 846504005253 |
AC Input Power: | 100 to 240 VAC, 50 / 60 Hz |
Box Dimensions (LxWxH): | 11.3 x 11.2 x 4.8" |
Built-In Speakers: | No |
CPU: | Quad-Core:2 to 2.7 GHz |
Certifications: | FCC, CE, BSMI, VCCI, RCM, UKCA, CCC, Kcc |
Color: | Black |
Compatible Drive Interface: | SATA III |
Cooling: | 1 x 92 mm Fan |
Dimensions: | 9.14 x 6.5 x 4.25" / 232.2 x 165 x 108 mm |
Encryption: | AES-NI (Hardware-Based) |
Form Factor: | Desktop |
GPU: | Intel UHD Graphics 600 |
Hot-Swap Support: | Yes |
Inputs/Outputs: | 2 x USB-A 3.0 / 3.1/3.2 Gen 12 x RJ45 Gigabit Ethernet |
Installed Operating System: | No |
Link Aggregation and Failover Support: | Yes |
Max Cameras Supported: | 25 |
Max Concurrent Connections: | 1500 |
Max Folders: | 256 |
Max Groups: | 256 |
Max Sync Tasks: | 8 |
Max User Accounts: | 2048 |
Max Volume Number: | 64 |
Maximum Memory Capacity: | 6 GB |
Media Card Slots: | No |
Mobile App Compatible: | Yes:Android & iOS*As of June, 2023:Check with manufacturer for the most up-to-date compatibility |
Noise Level: | 22 dBA |
Number of Bays: | 2 x 2.5"/3.5" |
Operating Altitude: | 16,404' / 5000 m |
Operating Humidity: | 5 to 95% |
Operating Temperature: | 32 to 104°F / 0 to 40°C |
PSU Wattage: | 1 x 60 W |
Package Weight: | 4.925 lb |
Power Consumption: | 14.69 W (Typical)4.41 W (Standby) |
Power Source: | AC Adapter |
Processor: | Intel Celeron J4125 |
RAID: | RAID 0, 1, JBOD, Synology Hybrid |
Security Features: | Kensington Security Slot |
Status Monitoring: | LED Indicator |
Storage Temperature: | -5 to 140°F / -20 to 60°C |
Supported Browsers: | Chrome, Edge, Firefox, Internet Explorer, Safari |
Supported File Systems: | Internal:BTRFS, EXT4External:BTRFS, EXT3, EXT4, FAT, HFS+, NTFS, exFAT |
Supported Languages: | Brazilian PortugueseCzechDanishDutchEnglishFrenchGermanHungarianItalianJapaneseKoreanNorwegianPolishPortugueseRussianSimplified ChineseSpanishSwedishThaiTraditional ChineseTurkish |
Supported Protocols: | AFPCIFSCalDAVFTPHTTPHTTPSL2TPLDAPNFSOpenVPNPPTPSMBSMB 2.1SMB 3.0SNMPSSHTelnetWebDAViSCSI |
Total Installed Memory: | 2 GB DDR4 |
Total Memory Slots: | 1 x SO-DIMM |
VPN Server Connections: | 40 |
Wake on LAN: | Yes |
Weight: | 2.9 lb / 1.3 kg |
iSCSI LUN: | 256 |
iSCSI Target: | 128 |
