4x DIMM Slot, Up to DDR5-8000 (OC) Unbuffered memory (Up to 192GB)
Intel XMP or AMD EXPO
4x SATA III 6 Gbps
2x M.2 22110/2280 PCIe Gen 4x4
1x M.2 22110/2280 PCIe Gen 5x4
1x PCIe X16 Gen 5 Slot
2x PCIe X16 Slot @ Gen 3 X1
Wi-Fi 6E 2x2 + Bluetooth 5.3
2.5G RJ-45 Lan
Back Panel Connector:
1 x Q-Flash Plus button
2 x antenna connectors (2T2R)
1 x HDMI port (4K@60Hz)
1 x USB Type-C® 3.2 Gen 2x2 20 Gbps (USB4 40 Gbps with Ryzen 8000 series), DP 1.4 (4k@144Hz)
2 x USB 3.2 Gen 2 Type-A ports (red)
5 x USB 3.2 Gen 1 ports
4 x USB 2.0/1.1 ports
1 x RJ-45 port
3 x audio jacks
USB Headers:
1 x USB Type-C® header, with USB 3.2 Gen 2x2 support
1 x USB 3.2 Gen 1 header
2 x USB 2.0/1.1 headers
Product Info
Product Description:
Key Features
AMD Socket AM5:Supports AMD Ryzen™ 7000 / Ryzen™ 8000 Series Processors
Digital twin 12+2+2 phases VRM solution
Dual Channel DDR5:4*DIMMs with AMD EXPO™ & Intel® XMP Memory Module Support
PCIe UD Slot X: PCIe 5.0 x16 slot with 10X strength for graphics card
EZ-Latch Click:M.2 heatsinks with screwless design
EZ-Latch Plus:M.2 slots with Quick Release & Screwless Design
Sensor Panel Link:Onboard video port for hassle-free in-chassis panel setup
UC BIOS:User-Centred intuitive UX with Quick Access function
Ultra-Fast Storage:3*M.2 slots, including 1* PCIe 5.0 x16
Efficient Overall Thermal:VRM Thermal Armor Advanced & M.2 Thermal Guard XL
Fast Networking:2.5GbE LAN & Wi-Fi 6E with Ultra-high gain antenna
Extended Connectivity:HDMI, Rear USB-C® support up to 40Gb/s, Front USB-C® 20Gb/s
Reliable Audio:8-Ch HD Audio & Audiophile Grade Capacitors
OVERVIEW
Performance
Thermal
Connectivity
DIY Friendly
AMD Ryzen
CPU Optimized
All Digital
Power
Best DDR5
Compatibility
Full Metal
Thermal
DIY-Friendly
Design
Robust VRM Design
Power in number
All AORUS series gaming motherboards are equipped with an all-digital power design, which delivers the best stability under heavy workloads.
Digital Twin VRM Design
Ensures stable high-power delivery for advanced overclocking.
* 6+6 phases parallel power design
12
VCORE Phases 60A Dr.MOS
to unleash the full potential of multi-core CPU performance.
2
SOC Phases 60A Dr.MOS
for CPU integrated GPU performance and memory control.
2
MISC Phases
provide stable power for CPU-connected PCIe lanes.
Memory
Memory, to the future
All AORUS series gaming motherboards feature multiple techniques to enhance the performance of DDR5 memory with the best compatibility.
Best-in-class Compatibility
DDR5 Overclocking Up to
8000 MT/s
* Memory overlocking and EXPO/XMP support may vary. Please note that product features may vary by model.
BIOS Engineering
Feature-rich BIOS functions that enable easy access to the best-in-class DDR5 performance.
DDR5 Auto Booster
one click to boost native DDR5-4800 to
Twin 12+2+2 Phases Digital VRM Solution, 6-Layer 2X Copper PCB
cutting-edge_thermal_design:
M.2 Thermal Guard XL, VRM Thermal Armor
ddr5_compatible:
4*DIMMs with AMD EXPO & Intel XMP Memory Module Support
ecc_supported:
Non-ECC
ez-latch_plus:
PCIe 5.0 & M.2 Connectors with a Quick Release & Screwless Design
fast_networking:
Intel 2.5GbE LAN, Wi-Fi 6E
maximum_memory_supported:
192GB
memory_standard:
Support for DDR5 8000(OC)/ 7800(OC)/ 7600(OC)/ 7200(OC)/ 7000(OC)/ 6800(OC)/ 6666(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5600(OC)/ 5200/4800/4400 MT/s memory modules
next_gen_connectivity:
PCIe 5.0, 3x M.2, Dual USB-C, BT 5.3
number_of_memory_slots:
4x288pin (DDR5)
Community Notes
This collaborative space allows users to contribute additional information, tips, and insights to enhance the original deal post. Feel free to share your knowledge and help fellow shoppers make informed decisions.
It's a pretty good motherboard. I got this board as a Micro Center combo and it plays much nicer with ram than the other B650 boards from MSI and Asus that I tried out.
One typo they have is "Fast Networking: Intel 2.5GbE LAN, Wi-Fi 6E". The Wi_Fi6e is Intel AX210 but the LAN is the Realtek Gaming 2.5GbE Family Controller. Both LAN and Wi-Fi works flawlessly.
It's a pretty good motherboard. I got this board as a Micro Center combo and it plays much nicer with ram than the other B650 boards from MSI and Asus that I tried out. One typo they have is "Fast Networking: Intel 2.5GbE LAN, Wi-Fi 6E". The Wi_Fi6e is Intel AX210 but the LAN is the Realtek Gaming 2.5GbE Family Controller. Both LAN and Wi-Fi works flawlessly.
I thought the one from Microcenter is B650 not B650E? Cause I recently made a build at MC with 9700X bundled with this B650 gaming AX v2 motherboard + 5080 for 2k
I thought the one from Microcenter is B650 not B650E? Cause I recently made a build at MC with 9700X bundled with this B650 gaming AX v2 motherboard + 5080 for 2k
You're right. I saw the B650 on the second part of the title and missed the B650E. I still stand by my support for Gigabyte (first time saying something good in a while) on their more higher end boards. I can't say anything good about their basic boards.
