Link:
https://store.minisforum.com/prod...1918824693
Coupon: $50 Off via
2025-50 (Automatically applies to the Cart)
Spec:
- AM5 CPU socket supporting Ryzen 7000, 8000 and 9000 series Desktop Processors
- 2x DDR5 SODIMM Slot, up to 96GB 5200 MT/s
- 2x PCIe Gen 4x4 M.2 2280 Slot
- 1x PCIe Gen 3x4 M.2 2280 Slot
- 1x PCIe Gen 4x1 M.2 2280 Slot
- 1x M.2 2230 for NIC (Populated)
- Wi-Fi 6E 2x2 + Bluetooth 5.2
- Front Ports:
- 2x USB-A 3.2 Gen 1
- 1x USB-A 2.0
- 1x 3.5mm Audio Combo Jack
- Rear Ports:
- 1x DC-In (19V 12.63A, 240W)
- 1x HDMI 2.1
- 1x DisplayPort 2.0
- 1x OCuLink Dedicated Port
- 1x USB 4.0 Type-C 40 Gbps (Data + DisplayPort)
- 1x USB-A 3.2 gen 2 10 Gbps
- 1x USB-A 2.0
- 2x Realtek 2.5G RJ-45 supporting link aggregation
Features:- Supports Raphael (Ryzen 7000 desktop), Phoenix (Ryzen 8000 series Desktop) and Granite Ridge (Ryzen 9000 series Desktop) Processor.
- The 3 M.2 PCIe Gen 4 SSD bandwidth depends upon the CPU choice as the Phoenix APUs don't offer as many PCIe Gen 4 lanes as the Ryzen 7000 series Desktop Processors. If 8000 series is used, the 2nd PCIe Gen 4x4 Slot will run at Gen 4x2 speed.
Leave a Comment
17 Comments
Sign up for a Slickdeals account to remove this ad.
Our community has rated this post as helpful. If you agree, why not thank SlickCrayon1512
Just FYI, $175 frequently
Also, buyer beware for buying directly from Minisforum. Buying from Amazon or Newegg gives you the opportunity to get an additional warranty... which given the complaints about Minisforum you might find to be a very useful alternative to their service/warranty support.
Sign up for a Slickdeals account to remove this ad.
Not at good deal, and also you need to carefully select a processor to be used as the cooling on this systems is really poor. Minisforum was smart to use a mobile chip in the next gen.
So I can't drop the 9950X I just got into this bad boy?
It's why the MS-02 which is basically the successor to this, uses the 9955HX which the mobile version with a much lower TDP but about 85-90% of the performance of the desktop 9950X.
So I can't drop the 9950X I just got into this bad boy?
Not if you don't want it throttled basically any time it's under load. You can use the best thermal paste possible but it won't make up for the significant deficiency in cooling.
It's why the MS-02 which is basically the successor to this, uses the 9955HX which the mobile version with a much lower TDP but about 85-90% of the performance of the desktop 9950X.
I have AOOSTER AG02 USB4/OCuLink eGPU Dock hich I use with my various Mini PCs and I have gamed on this with a RTX 4070 Ti at 1440p without any issues. However, main use case for this one is for me, is running multiple Databases, different Data Models and analytics software.
Just FYI, $175 frequently
When and where?
Edit: My original post was confusing.
