Click here [dd-wrt.com] for a guide on installing DD-WRT
Download the latest DD-WRT builds from here [dd-wrt.com]
If you are not interested in using custom firmware yet, these routers support mesh with the stock firmware, but the USB port is disabled.
The stock firmware is relatively new, but is speculated to not receive many, if any, updates, so it may be best to wait until custom firmware support is merged and more mature before messing with installing custom firmware.
How to enable mesh:
- Setup your Main router completely.
- Plug your child node using the wan port to the main router lan port, wait for a solid purple light on the child node before proceeding.
- Log into your main router web admin.
- Click on CA at the bottom right.
- Click on Connectivity and CA Router setup.
- Click on both Add Wired and Add Wireless nodes buttons. Wait for the Add wireless button to re-enable.
- Click Done adding Child Nodes and then Apply.
- Now the child node light should start flashing purple and turn into a mesh mode when it turns blue.
- Disconnect Ethernet and wait for blue light again.
- Move node to desired location.
How to set up as access point:
- Disable DHCP (optional).
- Set the device to Bridge Mode under Connectivity tab.
- Connect cable from your router to a LAN port.
- Get some nail polish and a round sticker to cover the annoying flashing right light.
- Click the 'CA' at the bottom of the page to see the detailed configurations of wifi.
to unbrick and flash new firmware
run flashimg
run flashimg2
rename stock firmware to tortuga.img
Leave a Comment
Your comment cannot be blank.
Share information with community. Please follow our Community Guidelines and be kind!
Top Comments
Mind you that I only have 100Mbps Spectrum internet but I do stream/direct play 4k videos from a Plex media server to several Amazon Firestick 4k devices without issue. Overall IMO you would be hard pressed to find such relatively decent hardware for so cheap; especially a Mesh network.
It wasn't all smooth at first mind you. I kept getting disconnects; especially with the streaming IP cameras. But I discovered by disabling Express Forwarding all my streaming issues went away. (CA>Connectivity>Administration>Express Forwarding)
I'm guessing that Cisco's/Linksys' proprietary Express Forwarding routing protocol was causing havoc with the IP cams streaming capabilities. Also, disabling Node Steering seemed to make things more stable as well; mesh nodes no longer disconnect from the router when Node Steering is disabled. (CA>Wi-Fi Settings>Advanced>Node Steering)
Of course, user experience can vary so feel free to experiment. if the routers are giving you problems, try turning these features off and see if it works
It's not a deal if you never receive it.
1,236 Comments
Sign up for a Slickdeals account to remove this ad.
In the Linksys app, I don't have account just login using router pwd the channels scan might have helped me.
That old TPlink is dated so this or other router should be improvement in WiFi speed but not coverage with only WiFiMan app from ubiquti is free and handy to compare speed etc
If you get 2 or 3 to use as mesh. Having each node focus on just the floor or few rooms the. Hand-off to next node.
I have been moving 2nd node around and see trade off, max speed whole 1st 2nd floor but then yard speed same as when I didn't have mesh. Move and yard max speed but some spots inside house are only 150-200mps etc
I only using two right now very small 2 story wood frame house in congested wifi surburb. I'm testing to help make sure these work before I give to brother or buddy with junk ATT or FIOS non mesh extender.
If you want headache free and less power usage just try to get newer TPlink. Even with apparent their recent firmware spying issues they have been reliable price performance with the right deal.
If these prices keep up it can become be like early WiFi days with Linksys the most common wifi pollution AP name.
Many non technical people buying and not realizing the 2 nodes not even successfully connected just sitting as a not working AP. Wasn't easy to get Node working but not that it is I've been able to move around, WiFi backhaul or wired. Seem fine
Mind you that I only have 100Mbps Spectrum internet but I do stream/direct play 4k videos from a Plex media server to several Amazon Firestick 4k devices without issue. Overall IMO you would be hard pressed to find such relatively decent hardware for so cheap; especially a Mesh network.
It wasn't all smooth at first mind you. I kept getting disconnects; especially with the streaming IP cameras. But I discovered by disabling Express Forwarding all my streaming issues went away. (CA>Connectivity>Administration>Express Forwarding)
I'm guessing that Cisco's/Linksys' proprietary Express Forwarding routing protocol was causing havoc with the IP cams streaming capabilities. Also, disabling Node Steering seemed to make things more stable as well; mesh nodes no longer disconnect from the router when Node Steering is disabled. (CA>Wi-Fi Settings>Advanced>Node Steering)
I've 3 units total in the mesh and am handy to setup DDWRT if it is.
It's not a deal if you never receive it.
Sign up for a Slickdeals account to remove this ad.
My amazon one for $25 has tracking since 3 days ago but has not been picked up
My amazon one for $25 has tracking since 3 days ago but has not been picked up
Our community has rated this post as helpful. If you agree, why not thank Dalant
Sign up for a Slickdeals account to remove this ad.
I don't care about the router functionality (not giving up my tp-links). I bought it to play with and have an extra router on hand from when I get the inevitable call from one of my kids that something is wrong with their internet. Cheaper to have an inexpensive back up on hand than to run to best buy to pick something up, been there a few times.
