This collaborative space allows users to contribute additional information, tips, and insights to enhance the original deal post. Feel free to share your knowledge and help fellow shoppers make informed decisions.
As many others have mentioned, yes you can. There are numerous guides on how to shuck them. There is also a community led Google doc that says which PSU models need the 3.3v mod.
It has nothing to do with the ATX PSU age or type. If you plug it into anything that provides power to the 3.3V pin, the drive will stay powered down. This is used to allow systems (typically backplanes) to disable or enable drives by controlling that one pin. If you plug these straight into an ATX power supply, which always provides a constant 3.3V to the power-disable pin, then the drive will stay "off."
People get around this by:
A) Using a Molex to SATA adapter when attached directly to a power supply, since Molex 4-pin doesn't have 3.3V to begin with.
B) Using it in enclosure that controls the power-disable pin correctly (or rather, doesn't have 3.3V and that pin just floats).
C) Using it in a server chassis that controls, or doesn't support, the power-disable pin. My servers have backplanes that are powered from 4-pin Molex connectors, and have no separate 3.3V regulator, so they could never send 3.3V if they wanted to. Just 12V and 5V on different pins.
I wonder if these can easily be shucked. If so, it's a good deal for some large (slow) storage for backups and such.
<edit> Answering my own question, from what I can tell these enclosures have WD140EDGZ drives in them, and they can be shucked and used without the enclosure.
Our community has rated this post as helpful. If you agree, why not thank CrazyBuckeye
I wonder if these can easily be shucked. If so, it's a good deal for some large (slow) storage for backups and such.
<edit> Answering my own question, from what I can tell these enclosures have WD140EDGZ drives in them, and they can be shucked and used without the enclosure.
I wonder if these can easily be shucked. If so, it's a good deal for some large (slow) storage for backups and such.
Answering my own question, from what I can tell these enclosures have WD140EDGZ drives in them, and they can be shucked and used without the enclosure.
They absolutely can, but you need to disable one of the pins with kapton tape.
Our community has rated this post as helpful. If you agree, why not thank KnockKnockWhosThere
Quote
from CrazyBuckeye
:
I wonder if these can easily be shucked. If so, it's a good deal for some large (slow) storage for backups and such.
Answering my own question, from what I can tell these enclosures have WD140EDGZ drives in them, and they can be shucked and used without the enclosure.
As many others have mentioned, yes you can. There are numerous guides on how to shuck them. There is also a community led Google doc that says which PSU models need the 3.3v mod.
Top Comments
Not sure if this is the most up to date version:
https://docs.google.com/spreadshe...A/htmlview
People get around this by:
A) Using a Molex to SATA adapter when attached directly to a power supply, since Molex 4-pin doesn't have 3.3V to begin with.
B) Using it in enclosure that controls the power-disable pin correctly (or rather, doesn't have 3.3V and that pin just floats).
C) Using it in a server chassis that controls, or doesn't support, the power-disable pin. My servers have backplanes that are powered from 4-pin Molex connectors, and have no separate 3.3V regulator, so they could never send 3.3V if they wanted to. Just 12V and 5V on different pins.
<edit> Answering my own question, from what I can tell these enclosures have WD140EDGZ drives in them, and they can be shucked and used without the enclosure.
Join The Conversation
Share your experience with the Slickdeals community
Share information with the community. Please follow our Community Guidelines and be kind!
157 Comments
Sign up for a Slickdeals account to remove this ad.
Our community has rated this post as helpful. If you agree, why not thank CrazyBuckeye
<edit> Answering my own question, from what I can tell these enclosures have WD140EDGZ drives in them, and they can be shucked and used without the enclosure.
Answering my own question, from what I can tell these enclosures have WD140EDGZ drives in them, and they can be shucked and used without the enclosure.
Our community has rated this post as helpful. If you agree, why not thank TwiceOver
Our community has rated this post as helpful. If you agree, why not thank Angrynapkin
I have a seasonic platinum 750w I think and I need to use the tape but my old server case with the backplane didn't.
I also only use these for my UnRaid server shucked. If you don't want to do the tape you can get adapters so I wouldn't worry about it.
Sign up for a Slickdeals account to remove this ad.
Our community has rated this post as helpful. If you agree, why not thank StreetJedi
Same price at:
BestBuy
Amazon
Newegg
Adorama
https://www.westerndigi
Our community has rated this post as helpful. If you agree, why not thank KnockKnockWhosThere
Answering my own question, from what I can tell these enclosures have WD140EDGZ drives in them, and they can be shucked and used without the enclosure.
Not sure if this is the most up to date version:
https://docs.google.com/spreadshe...A/htmlview
